Additional Options

Ramps

-94 in. x 3.25 in.

-7000 lbs.

-Aluminum Hook ends Ramp

​

​

or

​

-72"

-7000 lbs.

-Aluminum Hook ends Ramp

Wheel Tie Down Straps

  • Weather-resistant, highly visible yellow wrap around strap

  • 5,000 lb break strength / 1,666 lb working load

  • 5-1/2"L x 2"W (fits 13" - 16" tires)

  • Heavy duty non-slip ratchet

  • Not recommended for truck tires

  • Easy to use straps ideal for vehicle transportation and moving systems

  • Weather resistant strap with treaded wheel grips

  • Heavy duty non-slip ratchet

  • Three strong swivel hooks

  • High working load limit (WLL) of 1,393 lbs, with a break strength of 4,180 lbs

Winches

6,000 LB RECOVERY WINCH

Specifications Max Line Pull Max Line Speed Recommended Battery Max Amperage Overall Dimensions Weight 6,000 lbs. 13 fpm 650 CCA 280 Amps 17 x 6 x 8 78 lbs. Voltage Gear Train Gear Ratio Motor Mounting Bolt Pattern 12 Volts* 3 Stage Planetary 307:1 1.2 HP Series Wound 10 x 4 Pulling Load (lbs.) Line Speed (fpm.) Amperage 0 13 80 1,000 11 107 2,000 9 130 3,000 7 150 4,000 5 183 5,000 3 227 6,000 2 280

9,000 LB RECOVERY WINCH

​

 This winch can be configured to run on 12 Volts, 24 Volts, 110 Volts, or Hydraulics. The stall rating starts at 7,500 lbs. (110 Volt option) and goes up to 12,500 lbs. The solenoid now included is a single style compact solenoid which makes replacing much easier. The winch comes with a special blend of grease already applied to the inside. Grease zerks are included on the clutch housing to keep the clutch working smoothly. The winch has a simple mounting pattern where eight total bolts are inserted into the front and back of each housing. This allows for easy fabrication of custom mounts and efficient insertion into applications. (Note: Always be certain to use all mounting bolts when installing this winch.) The 110 Volt version has the option of either a momentary or continuous switch. The 12 and 24 Volt versions are wireless ready and come standard with a rugged and ergonomically designed rubber toggle switch remote. Specifications Max Line Pull Max Line Speed Brake Mechanism Max Amperage Overall Dimensions Weight 9,000 lbs. 14 fpm Worm Gear 400 Amps 16 x 8 x 13 92 lbs. Voltage Gear Train Gear Ratio Motor Clutch Type 12 Volts Worm Gear 470:1 1 HP Series Wound Dog

12,000 LB RECOVERY WINCH



Four way steel wire guide wheel allows multi-directional wire rope input. Includes wire rope, safety hook, snatch block, P040N 11' toggle switch remote, roller guide and electrical leads. Specifications Max Line Pull Max Line Speed Recommended Battery Max Amperage Overall Dimensions Weight 94 lbs. 12,000 lbs. 21 fpm 650 CCA 400 Amps 20 x 6 x 8 94 lbs. Voltage Gear Train Gear Ratio Motor Mounting Bolt Pattern 12 Volts* 3 Stage Planetary 265:1 6 HP Series Wound 10 x 4 Pulling Load (lbs.) Line Speed (fpm.) Amperage 0 21 65 500 19 80 1,000 16 96 2,000 11 126 4,000 9 175 6,000 8 230 8,000 7 280 10,000 6 365 12,000 4 400

​
